Wi-Fi Bridge RB554

The SiteHawk RB554 Wi-Fi Network Bridge extends your Wi-Fi network with five Ethernet Ports and an optional Hotspot radio in a compact industrial enclosure.

Featuring a high power 2.4GHz Uplink radio and our optimized roaming technology, the RB554 is the perfect all in one solution for providing connectivity to mobile machine based systems.

   Features & Benefits

  • High power dual antenna uplink radio providing a drop-in replacement migration path for legacy radios.
  • Hotspot model includes separate dual band radio for connecting nearby tablets, phones and laptops.
  • Optimized client roaming solution for intelligent selection of Access Points in a mobile environment.
  • 5 Industrial Ethernet ports enabling connectivity to onboard machine and vehicle devices.
  • Industrial enclosure and connectors provide protection from dust, moisture and vibration.
  • Universally compatible with any standard Wi-Fi network.
  • SNMP monitoring with dashboards and customized extensions capabilities enhance supportability.
  • NAT based routing simplifies deployments allowing a one step machine commissioning.
  • Firmware updates, configuration and commissioning manageable remotely ‘over the air’.
  • Wi-Fi Bridges can be swapped out as a single network appliance to simplify maintenance.
Monitoring
Integrations

Technical Specifications

Wi-Fi Radios

    Uplink

    Hotspot

2.4GHz 802.11 b/g/n Dual Antenna 30 dB (upgradable)

2.4/5GHZ 802.11 b/g/n/ac Dual Antenna 22dB

Ethernet Ports

5 x M12 Female D-coded (4pin)

Power

Voltage Input: 9-36V


Consumption: 200mA @ 24V (4.8W)


M12 Male T-Coded (4pin). 5 metre pre-terminated power cable supplied

Enclosure

Die-Cast Aluminium IP65 Rated

Dimensions

216mm (L) x 205mm (W) x 68mm (H)

Weight

1.35kg

Mounting

4 x M5 Mounting Holes
